Shenzhen Mottcell New Energy Technology Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | Mottcell |
| Model Number : | IFR 14500 500mAh |
| Supply Ability : | 50000 Piece/Pieces per Month |
| Price : | $10.00/pieces >=2 pieces |
| MOQ : | 1 Pcs |
Basic Information of IFR14500 Lithium Cell>>
Nominal Capacity | 500mAh | Cell Configuration | cylinder |
Mimimum Capacity | 480mAh | Internal Impedance | 90mΩ |
Nominal Voltage | 3.2V | Dimensions(mm) | 14.2mm(dia.)*50.2mm(ht.) |
Discharge Cut-off Voltage | 2.0V | Weight | 16 g |
Charge Cut-off Voltage | 3.65 V | Charge Temperature Range | 0°C~45°C |
Standard Charging Current | 100mAh | Discharge Temperature Range | -10°C~60°C |
Standard Discharge Current | 100mAh | Charge Method | CC/CV |
Fast Charging Current | 500mAh | Storage Temperature Range | Less than 1 year:-20~25°C |
Less then 3 months:-20~40°C | |||
Max Discharging Current | 1500mAh | Cycle Life (80% DOD) | >=2000 cycles |
Maximum Continuous Charge Current | 1C | Maximum Continuous Discharge Current | 3C |
Features
* High quality
* Factory price, fast delivery
* Long cycle life, No memory effec
* High safety, environment friendly
* High working voltage for single battery cells
* Widely application for electronics and industries
Model List: Li-ion 14500 battery
Model | Voltage | Capacity(mAh) | Weight (g) |
IFR14500J | 3.2V | 250 | 14 |
IFR14500J | 3.2V | 300 | 15 |
IFR14500J | 3.2V | 400 | 15.5 |
| IFR14500 | 3.2V | 500 | 16 |
| IFR14500J | 3.2V | 500 | 16.8 |
IFR14500 | 3.2V | 550 | 16.4 |
IFR14500J | 3.2V | 550 | 17 |
IFR14500J | 3.2V | 600 | 18 |
"J" stand for sharp top
DischargeTemperature | -10°C | 0°C | 23°C | 60°C |
DischargeCapacity(0.5C) | 50% | 80% | 100% | 95% |
Welcome you to consult our company website to look up other products. If you have any questions about our products, please feel free to contact me.
www.mottcell.com
|
|
